transport-passenger

Assignment Database System - Transport Passenger System

NodeJS, Sequelize (Postgres SQL), ReactJS, Express.JS, Heroku (App, Postgre), AWS (EC2, S3)

Quickstart

Quick review source code (Optional)

Install extension on Chrome

• Go chrome://apps/
• Choose Web Store
• Search Octotree and install the extension on Chrome
• After installation, a sidebar contains project tree will appear on the web

Code structure

• package.json: should view script to use
• index.js: start running node with babel (transform ES6, ES7 to ES5) and dotenv (environment variables)
• server.js: start server express
• test.js: only for testing somethings
• config/db.js: export environment variables for database
• server/config/sequelize: config package sequelize
• server/models: Define models schema of sequelize
• server/controllers: Controllers connect to database
• server/routes: Routes express
• server/documents: Database diagrams ERD
• server/scripts: Import SQL, database scripts
  • clear: truncate tables
  • create: create tables
  • drop: drop all tables
  • fake: fake data on your database
• admin-portal: front-end with ReactJS

Clone source code

git clone https://github.com/huynhsamha/transport-passenger.git

Configure database

Create .env in root project (the file is ignored in .gitignore, because of security for production)

This project use Postgres SQL.

The file as similar for development:

DB_HOST=localhost
DB_PORT=5432
DB_NAME=transport_passenger
DB_USERNAME=example_username
DB_PASSWORD=example_password

See file config/db.js that use the file to export configure the database.

Installation

# use npm
npm install
# or can use yarn
yarn

PostgresSQL - pgAdmin 3

Install postgres (database) and pgAdmin 3 (tool development)

Start development

Fake data before start

To drop all table in your schema (default of postres is public schema):

yarn run db:drop

To create tables:

yarn run db:create

To clear data of tables (only clear data, sequences not reset):

yarn run db:clear

After run db:create, you can fake data or import available data by following options:

To fake data (maybe catch error):

yarn run db:fake

To import data: Open pgAdmin 3 and run script file scripts/import-data.sql

Run NodeJS

Before start NodeJS, use Oracle SQL Developer or other ways to open localhost and port for database you use for the project.

After above step, run:

# use npm
npm start
# or can use npm
yarn start

Testing

Add your test files anywhere in server or test directory with *.spec.js

Run testing:

# use npm
npm run test
# or can use yarn
yarn test

Commit code

The project uses husky for pre-commit code, that lints your code (eslint) and detect your bug syntax js before commit or push.

Environments (development, test, production)

In file .env, add

# example for domain
DOMAIN=https://domain.com

# example for session secret
SESSION_SECRET=emCNrg59au2fvhgr5RA9TBxvWyBhPRw2RdjZAXR79v5JfDAKMX

# email for project
EMAIL_ADDRESS=noreply.transport.passenger@gmail.com
EMAIL_PASSWORD=[contact someone who know password]

# amazon aws
AWS_ACCESS_KEY_ID=[your access key aws]
AWS_SECRET_ACCESS_KEY=[your secret access key aws]
AWS_S3_BUCKET=transport-passenger

APIs

View APIs here

Documents - Contributing

View Documents here

Deploy Heroku

View instructions here

Deploy AWS

View instructions here
